Phantom Premium

Regular price $1,049.00
Unit price
per

In Stock. Ships within 3-5 days

Availability

Have questions? Your Pit Crew is here to help. Chat Now

Made In Canada

No Duties

No Taxes in the USA

Phantom Premium

The super frame without all the options. Build it up as you see fit. #yourrigyourway.

Included

1.5x4.5 Wheel Uprights

1.5x6 Spreader Profiles

Adjustable Wheel Side Mount

Pedal Plate 360

Options

Base Plates & Sim Feet

Side Mount

Front Profile

Inverted Pedal Kit

Wheel Base Mounting Options

Wheel Deck

compatible with

✅ Fanatec Clubsport, CSL Elite
✅ Logitech G25,27, 29, G920, G923
✅ Fanatec DD1, DD2,CSL-DD, GT-Pro
✅ Accuforce V1/V2
✅ Thrustmaster TX,T300, T500, T-GT, TS-P, TS-XW
✅ SimMagic M10
✅ Moza R5,R9,R16,R21

includes: Wheel Deck Mount plate 9.5mm (3/8 inch) -- 2 x 9.5mm adjustable side wheel mounts -- Made in Canada with Aluminum 6061 -- Powder coated in black

Front Mount

compatible with:

✅ All Simucube
✅ Fanatec Clubsport, CSL Elite
✅ MiGe 130st,
✅ SimMagic M10, Alpha, Mini
✅ Bondar
✅ VRS Direct Force Pro
✅ Lenze MCS12

includes: Front Wheel Mount plate 12.7.mm (1/2 inch) -- 2 x 9.5mm adjustable side wheel mounts -- Made in Canada with Aluminum 6061 -- Powder coated in black

Fanatec Mount

compatible with:

✅ Fanatec Podium DD1

✅ Fanatec Podium DD2

✅ Fanatec CSL DD

✅ Fanatec GT DD

includes: 2 x 9.5mm adjustable side wheel mounts -- Made in Canada with Aluminum 6061 -- Powder coated in black -- Choice between both CSL DD and Podium

Side Mounting Options

Option

Side Mount

22 inch long profile that can be raised or lowered. Can be used on left or right side.

OPTION

Shifter Plate

Includes: Shifter Mount Plate; Compatible with: Logitech, Thrustmaster, Fanatec

OPTION

Deluxe Kit

Includes: 2 x 180mm (7in) crossbars secured by 4 corner brackets easily mounting any shifter or handbrake.

Phantom Premium Specifications

Included

Phantom Frame

  • 52in long 1.5x6 inch Profile x 2
  • 32in tall 1.5x4.5 inch Profile x 2
  • 20in wide 1.5x6 inch Profile x 2
  • 20in long 1.5x1.5 inch Profile x 2
  • 1.5x1.5 Corner Brackets x 20
  • M8 Steel Bolts (class 12.9)
  • M8 Spring Loaded Drop in T-Nut

Pedal Plate 360

  • Pedal Plate 360 x 2
  • 19in 1.5x3 inch Aluminum Profiles x 2
  • M8 Steel Bolts (class 12.9)
  • M8 Spring Loaded Drop in T-Nuts

Choice of Wheel Mount

  • Wheel Deck, Front Mount (+$) Or Fanatec Mount
  • 2 x 9.5mm Side Wheel Mount Adjustable Connector Plates x2
  • M8 Steel Bolts (class 12.9)
  • M8 Spring Loaded Drop in T-Nuts

Premium Packaging

  • All parts identified and separated by assembly.
  • Welcome package with detailed step by step instructions.
  • Full set-up support throughout the assembly process.
  • All hardware to attach your wheel, pedals, shifter, seat, etc

Essentials Kit

  • Extra T-Nuts x 10
  • Extra M8 Bolts x 10
  • Velcro Tie Wraps x 10
  • 5mm Allen Key
  • 6mm Allen Key
  • Mount My Gear Kit

Options

Sim Feet & Base Plates

  • 4 x 3 hole 9.5mm thick base plates
  • 4 x 120mm high levelling feet x 4
  • 80mm scratch resistant rubber base
  • flanged head M12 Steel Nuts
  • M8 Steel Bolts (Class 12.9)
  • M8 Spring Loaded Drop in T-Nuts

Side Mount

  • 22in 1.5x3 inch Aluminum Profile
  • 14in 1.5x1.5 inch Sluminum Profile
  • 4 x 1.5x1.5 Corner Brackets
  • M8 Steel Bolts (Class 12.9)
  • M8 Spring Loaded Drop in T-Nuts
  • Option to add: / Shifter Plate / Deluxe Kit

Inverted Pedal Kit

  • 1.5 x 4.5 inch aluminum profiles to adjust pedal height x2
  • heel rest and a 1.5 x 3 cross profile to mount it
  • M8 Steel Bolts (Class 12.9)
  • M8 Spring Loaded Drop in T-Nuts

Dimensions:

Length: 1320mm / 52 inches

Width: 660mm / 26 inches

Height 812mm / 32 inches

Optional Sim Feet adds 100mm (4.4 inches) to the height and 90mm (3.35 inches) to the width

Warranty:

10 year warranty.

See Support Page for details.

Assembly Instructions:
